LENOVO ThinkEdge SE30 USFF - 11NA000DUK

LENOVO Logo here

Manufacturer Part Code: 11NA000DUK

Order Code: PBLEN-11NA000DUK

Category: Lenovo Desktops

Lenovo ThinkEdge SE30 11NA - USFF - Core i5 1145GRE / 1.5 GHz - vPro - RAM 16 GB - SSD 512 GB - NVMe - Iris Xe Graphics - GigE 2.5 GigE - WLAN: 802.11a/b/g/n/ac Bluetooth 5.1 - Win 10 IoT Enterprise - monitor: none - keyboard: UK - black - TopSeller

An IoT game changer
Tackling demanding tasks in demanding environments is what the ThinkEdge SE30 was designed for. Powered by the latest 11th Gen Intel® Core™ i5 vPro® processors for industrial computing and high-speed DDR4 memory, the SE30 is ready-built for challenging edge applications.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Essential Extras and Accessories

Technical Information

Certification
ErP Lot 6, Low Halogen, PCF
Certification
ErP Lot 6, Low Halogen, PCF
Compliance certificates
RoHS, WEEE
Chassis type
Mini PC
Chassis type
mini PC
Cable lock slot
Yes
Product colour
Black
Viewing window
No
Chassis type
Mini PC
Cable lock slot
Y
Volume
0.81 L
Colour of product
Black
Viewing window
N
Cable lock slot type
Kensington
Colour name
Black
Intel® vPro? Platform Eligibility
Yes
Cable lock slot type
Kensington
Display included
N
Power supply
65 W
Power supply
65 W
On-board graphics card model
Intel Iris Xe Graphics
Discrete graphics card model
Not available
On-board graphics card
Yes
Discrete graphics card
No
On-board GPU manufacturer
Intel
On-board graphics adapter model
Intel Iris Xe Graphics
Discrete graphics adapter model
Not available
On-board graphics adapter
Y
Discrete graphics adapter
N
Total storage capacity
512 GB
Internal memory type
DDR4-SDRAM
Maximum internal memory
16 GB
Internal memory type
DDR4-SDRAM
Memory clock speed
3200 MHz
Maximum internal memory
16 GB
Internal memory
16 GB
Memory clock speed
3200 MHz
Internal memory
16 GB
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version
5.1
Ethernet LAN
Yes
Antenna type
2x2
Bluetooth
Yes
Wireless LAN type
Wi-Fi 5 (802.11ac)
Wake-on-LAN ready
Yes
Wi-Fi
Yes
Ethernet LAN data rates
100,1000,2500 Mbit/s
Bluetooth version
5.1
Ethernet LAN connection
Y
Antenna type
2x2
Bluetooth
Y
Wake-on-LAN ready
Y
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
WLAN controller model
Intel Dual Band Wireless-AC 9560
Wireless LAN connection
Y
WLAN controller manufacturer
Intel
Ethernet LAN data transfer rates
1000,2500 Mbit/s
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
WLAN controller model
Intel Dual Band Wireless-AC 9560
WLAN controller manufacturer
Intel
Operating system installed
Windows 10 IoT Enterprise
Operating system provided
Windows 10 IoT Enterprise
Operating relative humidity (H-H)
20 - 80%
Storage temperature (T-T)
-40 - 60 °C
Operating temperature (T-T)
-20 - 60 °C
Operating shock
30 G
Storage temperature range (T-T)
-40 - 85 °C
Operating vibration
3 G
Operating temperature range (T-T)
-20 - 60 °C
Operating shock
30 G
Operating vibration
3 G
Optical drive type
N
Processor manufacturer
Intel
Trusted Platform Module (TPM)
Y
On-board graphics adapter
Y
Display included
No
Mouse included
Yes
Display included
N
Mouse included
Y
Keyboard included
Yes
Keyboard included
Y
Motherboard chipset
Intel SoC
Trusted Platform Module (TPM)
Yes
Product type
Mini PC
Trusted Platform Module (TPM)
Y
Product type
Mini PC
Serial ports quantity
2
Ethernet LAN (RJ-45) ports
2
DC-in jack
Yes
Serial ports quantity
2
DisplayPorts quantity
1
Combo headphone/mic port
Yes
DisplayPort version
1.4a
Ethernet LAN (RJ-45) ports quantity
2
DC-in jack
Y
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Thunderbolt 4 ports quantity
1
Intel® Thunderbolt 4
Yes
USB4 Gen 3x2 ports quantity
1
DisplayPorts quantity
1
Combo headphone/mic port
Y
DisplayPort version
1.4a
USB 3.0 (3.1 Gen 1) Type-A ports quantity
3
USB 3.1 (3.1 Gen 2) Type-C ports quantity
1
USB4 Gen 3x2 ports quantity
1
Processor model
i5-1145GRE
Number of processors installed
1
Processor manufacturer
Intel
Processor model
i5-1145GRE
Processor family
Intel® Core™ i5
Processor manufacturer
Intel
Processor cores
4
Processor threads
8
Processor boost frequency
4.1 GHz
Processor cache
8 MB
Processor family
11th gen Intel® Core™ i5
Processor frequency
1.5 GHz
Configurable TDP-down
12 W
Configurable TDP-down frequency
1.1 GHz
Configurable TDP-up frequency
2.6 GHz
Configurable TDP-up
28 W
Processor generation
11th gen Intel® Core™ i5
Processor number of cores
4
Turbo frequency (max)
4.1 GHz
Processor cache
8 MB
Processor clock speed
1.5 GHz
Configurable TDP-down
12 W
Configurable TDP-down frequency
1.1 GHz
Configurable TDP-up frequency
2.6 GHz
Configurable TDP-up
28 W
Idle States
Yes
Intel Trusted Execution Technology
Yes
CPU configuration (max)
1
Intel VT-x with Extended Page Tables (EPT)
Yes
Embedded options available
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Software Guard Extensions (Intel SGX)
No
Intel Virtualization Technology (VT-x)
Yes
Idle States
Y
Intel Trusted Execution Technology
Y
CPU configuration (max)
1
Intel VT-x with Extended Page Tables (EPT)
Y
Embedded options available
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Software Guard Extensions (Intel SGX)
N
Intel Virtualization Technology (VT-x)
Y
Cable lock slot
Y
Optical drive type
No
Total storage capacity
512 GB
Optical drive type
N
SSD interface
NVMe, PCI Express 3.0
SSD capacity
512 GB
Number of SSDs installed
1
Storage media
SSD
SSD form factor
M.2
NVMe
Yes
Total storage capacity
512 GB
Total SSDs capacity
512 GB
Solid-state drive interfaces
NVMe,PCI Express 3.0
Solid-state drive capacity
512 GB
Number of SSDs installed
1
Storage media
SSD
Total SSDs capacity
512 GB
Sustainability certificates
RoHS, WEEE
Sustainability certificates
RoHS, WEEE
Chassis type
Mini PC
Cable lock slot
Y
Colour of product
Black
Mouse included
Y
Trusted Platform Module (TPM)
Y
Product type
Mini PC
Cable lock slot type
Kensington
Sustainability certificates
RoHS, WEEE
On-board graphics adapter model
Intel Iris Xe Graphics
Discrete graphics adapter model
Not available
Weight
1.02 kg
Height
51.5 mm
Weight
1.02 kg
Width
179 mm
Depth
88 mm
Height
51.5 mm
Width
179 mm
Depth
88 mm
Bluetooth
Y
