Intel Solid State Drives (SSD) | INTEL Intel® SSD D3-S4510 Series (240GB, 2.5in SATA 6Gb/s, 3D2, TLC) | SSDSC2KB240G801 | ServersPlus

Illustration purposes only

INTEL Intel® SSD D3-S4510 Series (240GB, 2.5in SATA 6Gb/s, 3D2, TLC)

INTEL Logo here

Manufacturer Part Code: SSDSC2KB240G801

Order Code: HDINT-SSDSC2KB2C

Category: Intel Solid State Drives (SSD)

Intel Solid-State Drive D3-S4510 Series - Solid state drive - encrypted - 240 GB - internal - 2.5 - SATA 6Gb/s - 256-bit AES

Enhanced Power Loss Data Protection

Enhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.

Hardware Encryption

Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.

Temperature Monitoring and Logging

Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.

End-to-End Data Protection

End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Intel® Rapid Start Technology
N
Intel® Smart Response Technology
N
Intel High Endurance Technology (HET)
N
Intel Smart Response Technology version
0.00
Intel® Remote Secure Erase
N
Intel® Rapid Start Technology
N
Intel® Smart Response Technology
N
Intel High Endurance Technology (HET)
N
Intel Smart Response Technology version
0.00
Product family
Data center SSD
Product series
Intel® SSD D3-S4510 Series
Product codename
Youngsville Refresh
Intel® Remote Secure Erase
N
Colour of product
Silver
Data transfer rate
6 Gbit/s
Read speed
560 MB/s
Write speed
280 MB/s
Latency (read)
36 µs
Latency (write)
37 µs
Random read (100% span)
90000 IOPS
Colour of product
Silver
Component for
Server/workstation
SSD form factor
2.5"
Market segment
Server
Product family
Data center SSD
Product series
Intel® SSD D3-S4510 Series
Product codename
Youngsville Refresh
Mean time between failures (MTBF)
2000000 h
Power consumption (idle)
1 W
Power consumption (idle)
1 W
Interface
Serial ATA III
Security algorithms
256-bit AES
Mean time between failures (MTBF)
2000000 h
Memory type
TLC 3D NAND
Interface
Serial ATA III
Data transfer rate
6 Gbit/s
Read speed
560 MB/s
Write speed
280 MB/s
Security algorithms
256-bit AES
Mean time between failures (MTBF)
2000000 h
Memory type
TLC 3D NAND
Data transfer rate
6 Gbit/s
Read speed
560 MB/s
Write speed
280 MB/s
SSD capacity
240 GB
Component for
Server/workstation
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Read latency
36 µs
Write latency
37 µs
Enhanced Power Loss Data Protection technology
Y
Random write (100% span)
16000 IOPS
Random read (100% span)
90000 IOPS
Hardware encryption
Y
SSD temperature monitoring
Y
End-to-End Data Protection
Y
SSD form factor
2.5"
Market segment
Server
Harmonized System (HS) code
84717070
SSD ARK ID
134910
NVMe
N
NAND flash type
TLC (Triple Level Cell)
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G162706
Temperature monitoring and logging
Y
SSD capacity
240 GB
Component for
Server/workstation
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Read latency
36 µs
Write latency
37 µs
Enhanced Power Loss Data Protection technology
Y
Random write (100% span)
16000 IOPS
Random read (100% span)
90000 IOPS
Hardware encryption
Y
SSD temperature monitoring
Y
End-to-End Data Protection
Y
SSD form factor
2.5"
Market segment
Server
Harmonized System (HS) code
8523510000
SSD ARK ID
134910
NVMe
N
NAND flash type
TLC (Triple Level Cell)
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G162706
Temperature monitoring and logging
Y
Memory type
TLC 3D NAND
Solid-state drive interfaces
Serial ATA III
Solid-state drive capacity
240 GB
Country of origin
Malaysia
Harmonized System (HS) code
84717070
Operating temperature (T-T)
0 - 70 °C
Operating shock
1000 G
Non-operating shock
1000 G
Maximum operating temperature
70 °C
Non-operating vibration
3.13 G
Operating vibration
2.17 G
Operating temperature range (T-T)
0 - 70 °C
Operating shock
1000 G
Non-operating shock
1000 G
Maximum operating temperature
70 °C
Non-operating vibration
3.13 G
Operating vibration
2.17 G
Operating / non-operating shock
1000 G/0.5 msec
Operating / non-operating shock
1000 G/0.5 msec
Product colour
Silver
Power consumption (active)
2.4 W
Processor family
Intel SSD D3
Product colour
Silver
Power consumption (active)
2.4 W
Processor family
Intel SSD D3
Sequential writing speed
280 MB/s
Sequential reading
560 MB/s
Status
Launched
SSD hardware encryption
AES 256 bit
SSD power consumption (active)
2.4W
SSD power consumption (idle)
1.0W
SSD endurance rating
0.9 PBW
Launch date
Q3''18
SSD shock
1000 G/0.5 msec
Drive capacity
240 GB
Last change
63903513
Product family
Data center SSD
Product series
Intel® SSD D3-S4510 Series
Product codename
Youngsville Refresh
Intel Rapid Start Technology version
0.00
Remote Secure Erase (RSE) technology version
0.00
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Sequential writing speed
280 MB/s
Sequential reading
560 MB/s
Status
Launched
SSD hardware encryption
AES 256 bit
SSD power consumption (active)
2.4W
SSD power consumption (idle)
1.0W
SSD endurance rating
0.9 PBW
Launch date
Q3''18
SSD shock
1000 G/0.5 msec
Drive capacity
240 GB
Last change
63903513
Product family
Data center SSD
Product series
Intel® SSD D3-S4510 Series
Product codename
Youngsville Refresh
Intel Rapid Start Technology version
0.00
Remote Secure Erase (RSE) technology version
0.00
Package weight
112 g
Interface
Serial ATA III
Security algorithms
256-bit AES
Mean time between failures (MTBF)
2000000 h
Memory type
TLC 3D NAND
Data transfer rate
6 Gbit/s
Read speed
560 MB/s
Write speed
280 MB/s
Solid-state drive interfaces
Serial ATA III
Solid-state drive capacity
240 GB
Component for
Server/workstation
Intel Rapid Start Technology
N
Intel Smart Response Technology
N
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Latency (read)
36 µs
Latency (write)
37 µs
Enhanced Power Loss Data Protection technology
Y
Random write (100% span)
16000 IOPS
Random read (100% span)
90000 IOPS
Intel High Endurance Technology (HET)
N
Hardware encryption
Y
SSD temperature monitoring
Y
End-to-End Data Protection
Y
SSD ARK ID
134910
NVM Express (NVMe) supported
N
NAND flash type
TLC (Triple Level Cell)
Security algorithms supported
256-bit AES
Interface
Serial ATA III
Operating temperature (T-T)
0 - 70 °C
Operating shock
1000 G
Colour of product
Silver
Power consumption (active)
2.4 W
Non-operating shock
1000 G
Non-operating vibration
3.13 G
Operating vibration
2.17 G
Power consumption (idle)
1 W
SSD temperature monitoring
Y
Product type
19
Sequential writing
280 MB/s
Sequential reading
560 MB/s
Intel Smart Response Technology version
0.00
Status
Launched
SSD hardware encryption
AES 256 bit
SSD power consumption (active)
2.4W
SSD power consumption (idle)
1.0W
SSD form factor
2.5"
SSD endurance rating
0.9 PBW
Launch date
Q3''18
SSD shock
1000 G/0.5 msec
Drive capacity
240 GB
Market segment
Server
Weight
110 g
Height
7 mm
Width
17 mm
Depth
115 mm
Height
7 mm

#
