Ubiquiti UniFi AFI-G-UK AmpliFi Mesh Gaming WiFi System

Ubiquiti AmpliFi HD Home WiFi Mesh NVIDIA Gamer's Edition - AFI-G-UK. The Ubiquiti AmpliFi HD Gamer's Edition kit includes an AmpliFi Mesh Router along with 2wireless MeshPoints. The AFI-G combines deployment flexibility and simplicity with maximum WiFi coverage for your home.

With turbocharged 802.11ac Wi-Fi mesh technology, AmpliFi HD Gamer's Edition utilizes multiple self-configuring radios and advanced antenna technology to deliver powerful, whole-home Wi-Fi coverage.

The AmpliFi HD Gamer's Edition is equipped with a GeForce NOW QoS mode, developed by Ubiquiti with NVIDIA's support to quickly adjust networks for optimal game-streaming performance.

The QoS implementation offers gamers a simple solution for detecting latency or frame-loss issues, resulting in a top-quality experience when other traffic is present on the network.

System Specifications

Max. TX Power 26 dBm
Radios 6
MIMO Chains 18
Speed 5.25 Gbps

Router Specifications

Dimensions
99.5 x 97.8 x 99.6 mm (3.91 x 3.85 x 3.92")

Weight
0.410 kg (14.46 oz)

Max. TX Power
26 dBm

Radios
2

MIMO Chains
6

Speed
1750 Mbps

Networking Interface
Wi-Fi/Gigabit Ethernet (1) WAN, (4) LAN

Max. Power Consumption
11W

Buttons
Reset

ESD/EMP Protection
± 24kV Air/Contact

Antennas
(1) Dual-Band Antenna, Tri-Polarity

Display
40.6 mm (1.6") Diagonal, 240 x 240, 212 ppi, G+F Touch, Full Color

Wi-Fi Standards
802.11ac

Power Save
Supported

Wireless Security
WPA2-PSK AES/TKIP

Operating Temperature
-10 to 55° C (14 to 131° F)

Operating Humidity
5 to 95% Noncondensing

Certifications
FCC, CE, IC

Supported Data Rates (Mbps)

802.11ac 13 Mbps to 1300 Mbps (MCS0 - MCS9, VHT 20/40/80)
802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Meshpoint Specifications

Dimensions
228 x 54 x 57.1 (8.98 x 2.13 x 2.25")

Weight
0.165 kg (5.82 oz)

Max. TX Power
26 dBm

Radios
2

MIMO Chains
6

Speed
1750 Mbps

ESD/EMP Protection
± 24kV Air/Contact

Wi-Fi Standards
802.11ac

Wireless Security
WPA2-PSK AES/TKIP

Buttons
Reset

Antennas
(1) Dual-Band Antenna, Tri-Polarity

Power
Save Supported

Operating Temperature
-10 to 55° C (14 to 131° F)

Operating Humidity
5 to 95% Noncondensing

Certifications
FCC, CE, IC
