Wired Routers | DRAYTEK Vigor 3910 Multi-WAN Broadband Router | V3910-K | ServersPlus

Illustration purposes only

DRAYTEK Vigor 3910 Multi-WAN Broadband Router

DRAYTEK Logo here

Manufacturer Part Code: V3910-K

Order Code: NPDRA-V3910

Category: Wired Routers

Vigor 3910 Multi-WAN Broadband Router

Please note: For next business day delivery, this item must be ordered before 2:00pm

The Vigor 3910 is a Multi-WAN VPN Router designed for high performance and capable of handling the requirements of large and complex networks, with applications including Remote Access, Firewalling, Load-Balancing and Failover.

Featuring 12 LAN and WAN interfaces in total, 4 dedicated LAN ports and 8 switchable ports that can operate as LAN or WAN ports to fit your network requirements.

With up to 9Gb/s of NAT & Firewall throughput, the Vigor 3910 is suitable for the most demanding and bandwidth intensive SME applications. Each of the WAN ports on the Vigor 3910 can be grouped together to provide Load Balancing or operate as Failover or Backup WAN connections.

Based on the familiar DrayOS platform, the Vigor 3910 combines high performance and capacity with DrayTek's traditional ease of use and comprehensive feature set.

For multi-tenant or departmental flexibility, the Vigor3910 will support multiple LAN IP subnets, together with VLAN capabilities and user management, providing access to WAN resources only to the appropriate users or departments, as well as maintaining infrastructure efficiency.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Rack mounting
Y
Colour of product
Black, White
Rack capacity
1U
Power consumption (typical)
35 W
AC input voltage
220 - 240 V
Ethernet LAN data transfer rates
10,100,1000,2500,10000 Mbit/s
Built-in processor
Y
Quality of Service (QoS) support
Y
Web-based management
Y
Reset button
Y
Firmware upgradeable
Y
Networking standards
IEEE 802.1Q
Multicast support
Y
Ethernet LAN data rates
10,100,1000,2500,10000 Mbit/s
VLAN support
Y
Network address translation (NAT)
Y
Ethernet interface type
10 Gigabit Ethernet
Forwarding rate
3300 Mpps
Traffic control
Y
Throughput
9 Gbit/s
Policy-based routing
Y
Operating relative humidity range
10 - 90%
Storage temperature range (T-T)
-10 - 55 °C
Operating temperature range (T-T)
0 - 45 °C
AC adapter included
Y
Cables included
LAN (RJ-45)
Quick start guide
Y
AC adapter included
Y
Cables included
LAN (RJ-45)
Quick start guide
Y
Firmware upgradeable
Y
Built-in processor
Y
Ethernet LAN (RJ-45) ports quantity
8
RS-232 ports
1
USB version
2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity
2
Installed SFP+ modules quantity
2
Routing protocols
BGP,OSPFv2,RIP-1,RIP-2,RIPng
DHCP client
Y
DHCP server
Y
DMZ support
Y
Security algorithms supported
HTTPS,SSH
VPN tunnels quantity
500
IP address filtering
Y
DoS attack prevention
Y
Network address translation (NAT)
Y
Firewall
Y
URL filtering
Y
Rack mounting
Y
Colour of product
Black, White
Firmware upgradeable
Y
Built-in processor
Y
Policy-based routing
Y
Ethernet WAN
Y
Weight
3.23 kg
Height
45 mm
Width
443 mm
Depth
285 mm
