Ubiquiti US-8-60W UniFi 8 Port 60W PoE Managed Gigabit Network Switch

Ubiquiti Logo here

Manufacturer Part Code: US-8-60W

Order Code: NPUBI-US860W

Category: Switch Finder

Ubiquiti US-8-60W UniFi 8 Port 60W PoE Managed Gigabit Network Switch

Fully Managed Gigabit Switch

The UniFi Switch 8-port models feature Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switching for your networks.

8-Port Managed Gigabit Switches
The US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. Its auto-sensing PoE ports deliver up to 15.4W of power per port.

Non-Blocking Throughput
The new 8-port models feature Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps.

Switching Capacity
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.

Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

Specifications

Model: US-8-60W
Total Non-Blocking Throughput: 8 Gbps
Gigabit RJ45 Ports: 8
PoE Ports: 4 Auto-Sensing IEEE 802.3af PoE Ports
Switching Capacity: 16 Gbps
Max. Power Consumption: 12W


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Essential Extras and Accessories

Technical Information

Switching capacity
16 Gbit/s
Jumbo frames support
Yes
Forwarding rate
11.9 Mpps
Throughput
8 Mpps
Packet forwarding rate (1 Gbps)
11900 pps
Certification
ETSI300-019-1.4, CE, FCC, IC
LED indicators
Activity, Link, PoE, Speed
Wall mountable
Yes
Product colour
Grey
Reset button
Yes
Housing material
Steel
Output voltage
48 V
Output current
1.25 A
Power consumption (max)
12 W
Harmonized System (HS) code
85176990
Switch type
Managed
Networking standards
IEEE 802.1x, IEEE 802.3af
Flow control support
Yes
Port mirroring
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
VLAN support
Yes
10G support
No
Auto-sensing
Yes
Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-5 - 45 °C
AC adapter included
Yes
Processor frequency
400 MHz
Internal memory
256 MB
Flash memory
32 MB
Memory type
DDR3-SDRAM
Built-in processor
Yes
Harmonized System (HS) code
85176990
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
8
Power connector
DC-in jack
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
4
Total Power over Ethernet (PoE) budget
60 W
Power over Ethernet (PoE) voltage range
57 - 44 V
Power over Ethernet (PoE) power per port
15.4 W
Security algorithms
802.1x RADIUS
Weight
432 g
Height
30.7 mm
Width
148 mm
Depth
99.5 mm
