Ubiquiti UAP-NANOHD UniFi nanoHD 4x4 Wave2 MU-MIMO Wireless PoE Access Point

Ubiquiti Logo here

Manufacturer Part Code: UAP-NANOHD

Order Code: NPUBI-UAPNANOHD

Category: Ubiquiti Wireless Access Points

Ubiquiti UAP-NANOHD UniFi nanoHD 4x4 Wave2 MU-MIMO Wireless PoE Access Point

The Newest Price / Performance Leader in Enterprise Wi-Fi

Powered by Software Defined Networking
Easily deploy your UniFi Enterprise System using the included UniFi Controller software. Manage thousands of UniFi devices across multiple sites, and scale your network as needed without any ongoing licensing fees.

Intuitive, Graphical UI
Centralized Control via Easy-to-Use Interface

Real-Time Status
Real-Time Data Collection and Analysis

Breakthrough RF Mapping
RF Maps with Predictive Coverage

Hotspot Setup
Billing Integration, Vouchers, RADIUS, and Guest Controls

DPI Analytics
Deep Packet Inspection

Advanced Security
Secure Network and Clients

Designed for Seamless Integration
The UniFi nanoHD Access Point features a low-profile form factor. The optional ceiling mount or custom skins allow the AP to blend even more discreetly into its setting.

Our Smallest Access Point
Our Smallest UniFi Access Point Available On the Market. UAP nanoHD is 30% smaller than UAP AC Pro version.

Specifications

Model: UAP-nanoHD
Dimensions: 160x32.65mm
Environment: Indoor
2.4GHz Speed: 300Mbps
5GHz Speed: 1733Mbps
PoE Mode: 802.3af PoE
Ports: (1) 10/100/1000 Ethernet
Wi-Fi Users: 200+ Users
Mounting: Wall/Low-Profile Ceiling
MIMO Chains: 4x4
MU-MIMO: Yes
Skins: Optional


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Antenna gain level (max)
3 dBi
Integrated antenna
Y
Throughput
300 Mbps/1733 Mbps
Certification
CE, FCC, IC
Data transfer rate (max)
1733 Mbit/s
Ethernet LAN data transfer rates
10,100,1000 Mbit/s
Internal
Y
Certification
CE, FCC, IC
Colour of product
White
Reset button
Y
Placement
Ceiling, Wall
Power consumption (typical)
10.5 W
Input voltage
44 - 57
Power over Ethernet (PoE) Support
Y
Maximum data transfer rate
1733 Mbit/s
Number of users
200 user(s)
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q
Quality of Service (QoS) support
Y
Ethernet LAN data rates
10,100,1000 Mbit/s
VLAN support
Y
2.4 GHz
Y
5 GHz
Y
Wireless isolation
Y
Wi-Fi Multimedia (WMM)/(WME)
Y
MIMO
Y
MIMO type
Multi User MIMO
Quality of Service (QoS) support
Y
VLAN support
Y
Internal
Y
Number of users
200 user(s)
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q
Operating relative humidity range
5 - 95%
Operating temperature range (T-T)
-10 - 70 °C
Certification
CE, FCC, IC
Data transfer rate (max)
1733 Mbit/s
Number of users
200 user(s)
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q
Throughput
300 Mbps/1733 Mbps
Quality of Service (QoS) support
Y
Ethernet LAN data rates
10,100,1000 Mbit/s
Reset button
Y
VLAN support
Y
2.4 GHz
Y
5 GHz
Y
Wireless isolation
Y
Wi-Fi Multimedia (WMM)/(WME)
Y
MIMO
Y
MIMO type
Multi User MIMO
Ethernet LAN (RJ-45) ports quantity
1
DC-in jack
Y
Security algorithms supported
AES,TKIP,WEP,WPA,WPA-Enterprise,WPA-PSK,WPA2
SSID Broadcast on/off
Y
Number of SSID support
8
Height
32.6 mm
Input voltage
44 - 57
Weight
300 g
Height
32.6 mm
Width
160 mm
Depth
160 mm
Antenna gain level (max)
3 dBi
