ZYXEL WAX610D-EU0101F

ZYXEL Logo here

Manufacturer Part Code: WAX610D-EU0101F

Order Code: NPZYX-WAX610DEU0

Category: Zyxel Wireless Access Points

WAX610D Single Pack 802.11ax 2x2 Dual Optimized Antenna exclude Power Adaptor-1 year NCC Pro Pack license bundled Multigig Port E

True WiFi 6 experience for all

The WAX610D is designed to deliver the true WiFi 6 experience to users for various types of applications. Featuring 6 spatial streams (4x4:4 in 5GHz, 2x2:2 in 2.4GHz ), OFDMA and MU-MIMO capabilities, the WAX610D can provide fabulous efficiency for your wireless networking.

An access point that fits your need


We understand that mounting an access point to the ceiling isn't always possible due to the challenging environments like warehouses, historical buildings or stylish hotels where the aesthetics of the building are a priority. The WAX610D is equipped with a dual-optimized antenna that is selectable, allowing the access point to be mounted on the wall or on the ceiling without compromising on performance and coverage.

Hassle-free upgrade

To meet the growing demands for WiFi connectivity, the WAX610D enhances the network capacity with 2.90 Gbps WiFi speed and 2.5 Gbps multi-gigabit Ethernet port, which allows multi-gigabit speed run on the existing infrastructure without the need of re-cabling. The WAX610D enables organizations such as schools, hotels, and retail stores to upgrade to the latest WiFi 6 technology easily without breaking the bank.

Manage it your way!

The WAX610D comes with the support of NebulaFlex Pro, which offers the full flexibility for users to easily switch between cloud-managed, controller-managed, and standalone modes. You can choose the appropriate managed-mode best suited for your needs.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Antenna type
Internal
Antenna type
Internal
Data transfer rate (max)
2400 Mbit/s
Ethernet LAN data transfer rates
10,100,1000,2500 Mbit/s
Product colour
White
Colour of product
White
Placement
Wall
Placement
Wall
Power over Ethernet (PoE)
Yes
Input voltage
12 V
AC input voltage
12 V
Power over Ethernet (PoE) Support
Y
AC input voltage
12 V
Maximum data transfer rate
2400 Mbit/s
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
Maximum data transfer rate
2400 Mbit/s
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
VLAN support
Yes
2.4 GHz
Yes
5 GHz
Yes
MIMO
Yes
MIMO type
Multi User MIMO
Maximum data transfer rate (2.4 GHz)
575 Mbit/s
Maximum data transfer rate (5 GHz)
2400 Mbit/s
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
VLAN support
Y
2.4 GHz
Y
5 GHz
Y
MIMO
Y
MIMO type
Multi User MIMO
Maximum data transfer rate (2.4 GHz)
575 Mbit/s
Maximum data transfer rate (5 GHz)
2400 Mbit/s
Harmonized System (HS) code
85176990
VLAN support
Y
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Operating relative humidity (H-H)
10 - 95%
Storage temperature (T-T)
-30 - 70 °C
Operating temperature (T-T)
0 - 50 °C
Storage relative humidity (H-H)
10 - 90%
Operating relative humidity range
10 - 95%
Storage temperature range (T-T)
-30 - 70 °C
Operating temperature range (T-T)
0 - 50 °C
Storage relative humidity range
10 - 90%
Number of products included
1 pc(s)
Number of products included
1 pc(s)
Number of products included
1 pc(s)
Number of products included
1 pc(s)
Data transfer rate (max)
2400 Mbit/s
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
VLAN support
Y
2.4 GHz
Y
5 GHz
Y
MIMO
Y
MIMO type
Multi User MIMO
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
Ethernet LAN (RJ-45) ports quantity
1
DC-in jack
Y
DHCP client
0 - 50 °C
Security algorithms
EAP, WEP, WPA, WPA2
Security algorithms supported
EAP,WEP,WPA,WPA2
MAC address filtering
Yes
MAC address filtering
Y
Remote Authentication Dial-In User Service (RADIUS)
Yes
Remote Authentication Dial-In User Service (RADIUS)
Y
Height
64 mm
Input voltage
12 V
Harmonized System (HS) code
85176990
Weight
780 g
Height
64 mm
Weight
780 g
Width
229 mm
Depth
216 mm
Height
64 mm
Width
229 mm
Depth
216 mm
Antenna type
Internal
