Dell Desktops | DELL 7020 Plus | CGNJM | ServersPlus
L R
DELL CGNJM | serversplus.comDELL CGNJM | serversplus.comDELL CGNJM | serversplus.comDELL CGNJM | serversplus.comDELL CGNJM | serversplus.comDELL CGNJM | serversplus.com

Illustration purposes only

DELL 7020 Plus

DELL Logo here

Manufacturer Part Code: CGNJM

Order Code: PBDEL-CGNJM

Category: Dell Desktops

Intel Core i5-14500 (24MB Cache), 16GB DDR5-SDRAM, 512GB SSD, Intel UHD Graphics 770, LAN, WLAN, Bluetooth, Windows 11 Pro 64-bit

High performance commercial desktop with DDR5 memory, 10 native USBs including 1 USB-C, and 3 native DisplayPorts.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Essential Extras and Accessories

Technical Information

Total carbon footprint
167
Carbon emissions (Manufacturing)
86
Carbon emissions (Logistics)
12
Carbon emissions (Use)
65
Carbon emissions (End-of-Life)
5
Total carbon emissions (w/o Use phase)
102
PAIA version
GaBi version 1, 2024
Chassis type
SFF
Cable lock slot
Yes
Product colour
Black
Placement supported
Vertical
Cable lock slot type
Kensington
Water cooling system
No
Intel® vPro? Platform Eligibility
Yes
Display included
No
Power supply
260 W
Power supply input voltage
90 - 264 V
Power supply input frequency
47/63 Hz
80 PLUS certification
80 PLUS Bronze
PCI Express x4 (Gen 3.x) slots
1
PCI Express x16 (Gen 4.x) slots
1
On-board graphics card model
Intel UHD Graphics 770
Discrete graphics card model
Not available
On-board graphics card
Yes
Discrete graphics card
No
On-board graphics card family
Intel® UHD Graphics
On-board GPU manufacturer
Intel
Maximum on-board graphics card resolution
7680 x 4320 pixels
Internal memory type
DDR5-SDRAM
Memory slots
4x DIMM
Maximum internal memory
128 GB
Memory channels
Dual-channel
Memory layout (slots x size)
2 x 8 GB
Internal memory
16 GB
Memory data transfer rate
4400 MT/s
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Cabling technology
10/100/1000Base-T(X)
Ethernet LAN
Yes
Antenna type
2x2
Bluetooth
Yes
Wi-Fi
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
WLAN controller model
Intel Wi-Fi 6E AX211
WLAN controller manufacturer
Intel
Operating system installed
Windows 11 Pro
Trial software
Activate Your Microsoft 365 For A 30 Day Trial
Operating system architecture
64-bit
Operating system language
German, Dutch, English, French, Italian
Operating altitude
-15.2 - 3048 m
Operating relative humidity (H-H)
20 - 80%
Storage temperature (T-T)
-40 - 65 °C
Operating temperature (T-T)
10 - 35 °C
Storage relative humidity (H-H)
5 - 95%
Non-operating altitude
-15.2 - 10668 m
Non-operating shock
105 G
Non-operating vibration
1.37 G
Operating vibration
0.26 G
Contrast ratio (typical)
5 - 95%
Cables included
AC
Display included
No
Input device model
Dell Pro Wireless Keyboard and Mouse - KM5221W - UK (QWERTY) - Black
Motherboard chipset
Intel Q670
Built-in speaker(s)
No
Trusted Platform Module (TPM)
Yes
Market positioning
Business
Trusted Platform Module (TPM) version
2.0
Product type
PC
Audio chip
Realtek ALC3246-CG
Line-in
Yes
Line-out
Yes
USB 2.0 ports quantity
4
Ethernet LAN (RJ-45) ports
1
DisplayPorts quantity
3
Number of SATA III connectors
3
Combo headphone/mic port
Yes
DisplayPort version
1.4a
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Thunderbolt 3 ports quantity
0
PowerShare
Yes
Number of USB ports with PowerShare support
1
USB 3.2 Gen 2x2 Type-C ports quantity
1
Processor model
i5-14500
Number of processors installed
1
Processor manufacturer
Intel
Processor family
Intel® Core™ i5
Processor cores
14
Processor threads
20
Number of processors supported
1
Processor boost frequency
5 GHz
Processor cache
24 MB
Processor cache type
Smart Cache
Efficient cores
8
Performance cores
6
Processor base power
65 W
Maximum turbo power
154 W
Efficient-core base frequency
1.9 GHz
Performance-core base frequency
2.6 GHz
Processor generation
Intel® Core™ i5 (14th gen)
Efficient-core Max Turbo Frequency
3.7 GHz
Performance-core Max Turbo Frequency
5 GHz
Compatible memory cards
Not supported
Optical drive type
No
Total storage capacity
512 GB
SSD interface
PCI Express
SSD capacity
512 GB
RAID support
No
Number of SSDs installed
1
Storage media
SSD
Number of storage drives installed
1
SSD form factor
M.2
NVMe
Yes
Total SSDs capacity
512 GB
SSD performance class
35
Sustainability certificates
ENERGY STAR, TCO
Height
290 mm
Width
92.6 mm
Depth
292.8 mm
