STARTECH.COM 3 Port USB 3.0 C Hub - HB30C3AGEPD

STARTECH.COM Logo here

Manufacturer Part Code: HB30C3AGEPD

Order Code: ACSTA-HB30C3AGEB

Category: Docking Stations

3 Port USB 3.0 C Hub

Turn a laptop USB-C port into three USB Type-A ports (5Gbps) and one GbE port, plus power and charge your laptop

This 3-port USB 3.0 hub with Gigabit Ethernet couples your USB peripheral and RJ45 network connections into a single convenient hub, with support for USB Power Delivery. This means that you can power and charge your laptop through its USB-C port while simultaneously powering the hub.

With its integrated USB Type-C cable and small-footprint design, this versatile hub offers a perfectly portable solution for connecting devices that require traditional USB Type-A ports to your USB-C or Thunderbolt 3 equipped computer.

Merge two vital port types into one stylish hub

If your USB-C equipped laptop or MacBook is missing the ports you need, this hub can help. The versatile USB 3.0 hub gives you access to not only your USB peripheral devices but also a wired internet connection. It offers a Gigabit Ethernet port, so you can connect to a network in locations where Wi-Fi is unreliable or unavailable.

Connect your USB devices in seconds

This USB hub is multi-platform compatible, which means it will work with a wide range of USB-C laptops that use a USB-C power adapter. It also works with a range of operating systems such as Windows, macOS, Linux and Chrome OS. It automatically installs once you connect it to your laptop, so you can be up and running in seconds.

Carry fewer cables and power adapters

This USB-C 3.0 hub supports USB Power Delivery 2.0, so instead of carrying multiple cables and power adapters, you can use your laptop's USB-C power adapter to power both your laptop and the hub. By using just a single power adapter instead of two, you can eliminate clutter and hassle when you work.

Take it with you wherever you go

With its compact and rugged design, you can take this portable USB 3.0 hub anywhere you go. Because it's so compact, it's easy to tuck into your laptop bag and only takes up a small amount of desk space when you connect it to your workstation. For portable applications, having the integrated host (USB-C) cable means one less thing to remember to carry with you.

The HB30C3AGEPD is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- 3 PORT USB C HUB: Expand the connectivity of a USB-C computer by adding 3x USB-A (USB 3.0 SuperSpeed 5Gbps) & a Gigabit Ethernet RJ45 port for wired network connectivity (Wake-On-Lan, 10/100/1000Mbps)
- POWER AND CHARGE YOUR LAPTOP: USB-C hub supports Power Delivery (PD 2.0) up to 60W pass-through charging when used with your USB Type-C power adapter; 7.4W reserved for hub/downstream port operation
- SPEEDS UP TO 5Gbps: USB 3.0 SuperSpeed 5Gbps (USB 3.1 Gen 1 / USB 3.2 Gen 1) shared with all downstream devices, supports thumb drives, data storage devices, keyboards, mice, web cams, headsets


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Master (outer) case height
310 mm
Master (outer) case width
330 mm
Master (outer) case length
530 mm
Products per master (outer) case
60 pc(s)
Harmonized System (HS) code
84733020
Full duplex
Yes
Ethernet LAN
Yes
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN (RJ-45) ports
1
Flow control support
Y
Flow control support
Yes
Jumbo frames support
Y
Jumbo frames support
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Auto MDI/MDI-X
Yes
VLAN tagging
Y
VLAN tagging
Yes
Jumbo frames
9000
Operating relative humidity (H-H)
10 - 90%
Storage temperature (T-T)
-10 - 70 °C
Operating temperature (T-T)
0 - 45 °C
Chipset
VIA/VLI - VL100, VIA/VLI - VL813, Realtek - RTL8153
Cable length
0.15 m
Quick start guide
Yes
Package weight
115 g
Package depth
30 mm
Package height
142 mm
Package width
170 mm
Quantity per pack
1 pc(s)
Data transfer rate
5 Gbit/s
Product colour
Black
Card reader integrated
No
Housing material
Plastic
UASP support
Yes
Connectivity technology
Wired
Microphone in
No
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB Power Delivery
Yes
USB Power Delivery up to
60 W
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura
Linux operating systems supported
Yes
Server operating systems supported
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019
Harmonized System (HS) code
84733020
Weight
44.9 g
Height
170 mm
Width
41 mm
Depth
95 mm
