Fujitsu Primergy Rack Servers | FUJITSU RX2520 M5 8x 2.5 (Exp) 1x Silver 4208 1x 16GB 1x PSU 8xSFF | VFY:R2525SC010IN | ServersPlus
L R
FUJITSU VFY:R2525SC010IN | serversplus.comFUJITSU VFY:R2525SC010IN | serversplus.comFUJITSU VFY:R2525SC010IN | serversplus.comFUJITSU VFY:R2525SC010IN | serversplus.comFUJITSU VFY:R2525SC010IN | serversplus.comFUJITSU VFY:R2525SC010IN | serversplus.comFUJITSU VFY:R2525SC010IN | serversplus.com

Illustration purposes only

FUJITSU RX2520 M5 8x 2.5 (Exp) 1x Silver 4208 1x 16GB 1x PSU 8xSFF

FUJITSU Logo here

Manufacturer Part Code: VFY:R2525SC010IN

Order Code: SVFUJ-R2525SC010

Category: Fujitsu Primergy Rack Servers

Fujitsu PRIMERGY RX2520 M5 - Server - rack-mountable - 2U - 2-way - 1 x Xeon Silver 4208 / 2.1 GHz - RAM 16 GB - SATA - hot-swap 2.5 - GigE - no OS - monitor: none

This product qualifies for...
Up to £300 Cash Back with Microsoft Server software!
Fujitsu Reliability Promise - Get the cost back if it fails within a year!

The Fujitsu PRIMERGY RX2520 M5 is an efficient and scalable platform for essential business applications. Its dual sockets host Intel® Xeon® Scalable Family processors with up to 768 GB RAM. The PRIMERGY RX2520 delivers an especially well balanced price / performance ratio making it ideal for baseline datacenter workloads i.e. for collaboration platforms or storage-hungry applications. The system design offers room for future growth thanks to modular design approaches for variable base units, PSUs, controllers, LAN etc. iRMC S5 server management lowers operational costs additionally.

The variability of choice for the new generation ?Cascade Lake? processors are ideal for price/performance sensitive environments. The system offers well-enough scalability for memory and additional devices to complement small-scale virtualization or collaboration platforms.

The server is a scalable platform to best meet increasing individual demand optimized to suit serverized storage scenarios or storage demanding applications. Due to upgrade kits and the modular platform, just grow over time within the same system and utilize to the best over the entire lifecycle.

This allows a cost-efficient onboard Ethernet connection for almost all tasks and a simplified and comprehensive power management that results with the high efficient power supplies in significant savings. Fujitsu ServerView Suite provides all the functions for fail-safe, flexible and automated 24x7 server operations and improves end-user productivity via intelligent and innovative system management solutions.

Fujitsu offers comprehensive infrastructure management and server management solutions which is key to efficient data center operations. They provides all the functions for flexible and automated 24x7 IT operations and improves end-user productivity via intelligent and innovative system management solutions. ISM helps improve data center efficiency and overall IT Productivity with converged infrastructure management, paving the path to software-defined data center.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.
Need this delivered pre-built? We have configuration and installation options available!

Technical Information

Certification
CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
Rack mounting
Y
Chassis type
Rack (2U)
Redundant fans support
Y
Rack rails
Y
Power supply
450 W
Redundant power supply (RPS) support
Y
PCI Express slots version
3.0
PCI Express x8 (Gen 3.x) slots
3
PCI Express x16 (Gen 3.x) slots
1
On-board graphics card model
Not available
Harmonized System (HS) code
84714100
Internal memory type
DDR4-SDRAM
Memory slots
12
Maximum internal memory
384 GB
Memory clock speed
2933 MHz
Internal memory
16 GB
Cabling technology
10/100/1000Base-T(X)
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
Compatible operating systems
Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Operating system installed
N
Operating relative humidity (H-H)
10 - 85%
Operating temperature (T-T)
5 - 45 °C
Trusted Platform Module (TPM)
Y
Trusted Platform Module (TPM) version
2.0
Harmonized System (HS) code
84714100
USB 2.0 ports quantity
1
Ethernet LAN (RJ-45) ports
2
VGA (D-Sub) ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
Processor model
4208
Motherboard chipset
Intel® C624
Number of processors installed
1
Processor manufacturer
Intel
Processor lithography
14 nm
Maximum number of SMP processors
2
Processor family
Intel Xeon Silver
Processor socket
LGA 3647 (Socket P)
Supported instruction sets
AVX-512
Processor cores
8
Processor threads
16
Processor operating modes
64-bit
Processor boost frequency
3.2 GHz
Processor cache
11 MB
Execute Disable Bit
Y
Scalability
2S
Tcase
78 °C
Embedded options available
N
Processor frequency
2.1 GHz
Thermal Design Power (TDP)
85 W
Processor codename
Cascade Lake
Maximum number of PCI Express lanes
48
Maximum internal memory supported by processor
1024 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2400 MHz
Processor package size
76.0 x 56.5 mm
Processor generation
2nd Generation Intel® Xeon® Scalable
Intel® Hyper Threading Technology (Intel® HT Technology)
Y
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel TSX-NI
Y
Intel 64
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
Processor ARK ID
193390
Optical drive type
DVD-RW
RAID levels
0, 1, 10
Hot-Plug support
Y
Number of HDDs supported
8
Hot-swap
Y
RAID support
Y
Weight
25 kg
Height
86.6 mm
Width
482.4 mm
Depth
770 mm
