HPE ProLiant DL360 Gen10 Rack Server - P24743-B21

HPE Logo here

Manufacturer Part Code: P24743-B21

Order Code: SVHEW-P24743B21

Category: HPE Rack Servers

Intel Xeon-G 6248R 24-Core (3.00GHz 35.75MB) 32GB (1 x 32GB) PC4-2933Y-R DDR4 RDIMM 8 x Hot Plug 2.5in Small Form Factor Smart Carrier Smart Array S100i SATA NC No Optical 800W 3yr Next Business Day Warranty

Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing?

The HPE ProLiant DL360 Gen10 Server delivers security, agility and flexibility without compromise. Supports the Intel® Xeon® Processor Scalable Family with up to a 71% performance gain and 27% increase in cores, plus 2666 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB4 with an increase in performance up to 66%. With the added performance that 12 NVDIMMs and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy, update, monitor and maintain with ease by automating the most essential server lifecycle management tasks with HPE OneView and HPE iLO 5. Deploy this 2P secure platform for diverse workloads in space constrained environments.

Features

Industry-leading Performance with Versatile Compute
- The HPE ProLiant DL360 Gen10 Server supports industry standard technology leveraging Intel's latest Xeon® Processor Scalable Family with up to 28 cores, 12G SAS and 3.0 TB4 of HPE DDR4 2666 MT/s SmartMemory.
- With support for up to 12 NVDIMMs per chassis and 2X capacity of first generation HPE NVDIMMs, the HPE ProLiant DL360 Gen10 Server delivers up to 192 GB per system.
- Achieve greater capacity with flexible drive configuration options with up to ten SFF, four LFF drives along with option to support up to ten NVMe PCIe SSDs delivering optimal performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.
- HPE Persistent Memory, the world's first non-volatile DIMM (NVDIMM) optimized on HPE ProLiant compute, offers unprecedented levels of performance for databases and analytic workloads.

Innovative Design for Flexibility and Choice
- The Premium 10 SFF NVMe chassis backplane provides the ability to mix and match SAS/SATA and NVMe within the same chassis along with 8+2 SFF and 4 LFF chassis that supports new uFF and M.2 storage options.
- Embedded 4x1GbE plus HPE FlexibleLOM or PCIe standup 1GbE, 10GbE or 25GbE adapters which provides flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.
- Unmatched expandability packed in a dense 1U rack design with up to 3 PCIe 3.0 slots.

Security Innovations
- Only Hewlett Packard Enterprise offers industry standard servers with major firmware anchored directly into the silicon. with security protection built in across the server lifecycle starting with Silicon Root of Trust.
- Millions of lines of firmware code run before the server operating system boots and with Runtime Firmware Validation, enabled by iLO Advanced Premium Security Edition, the server firmware is checked every 24 hours verifying validity and credibility of essential system firmware.
- Secure Recovery allows server firmware to rollback to the to last known good state or factory settings after detection of compromised code.
- Additional security options are available with Trusted Platform Module (TPM) to prevents unauthorized access to server and securely stores artifacts used to authenticate the server platforms while the Intrusion Detection Kit logs and alerts when the server hood is removed.

Industry-Leading Serviceability and Deployment
- The HPE ProLiant DL360 Gen10 Server comes with a complete set of HPE Technology Services, delivering confidence, reducing risk and helping customers realize agility and stability.
- HPE Pointnext Services simplifies all stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an optimal solution. Professional Services enables rapid deployment of solutions and Operational Services provides ongoing support.
- Services provided under Operational Services include: Flexible Capacity, Datacenter Care, Infrastructure Automation, Campus Care, Proactive Services and Multi-vendor coverage.
- HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.
Need this delivered pre-built? We have configuration and installation options available!

Essential Extras and Accessories

£29.68 ex. VAT
£509.77 ex. VAT

Technical Information

Rack mounting
Y
Chassis type
Rack (1U)
Product colour
Black, Metallic
Rack mounting
Y
Chassis type
Rack (1U)
Optical drive type
N
Colour of product
Black, Metallic
Power supply
800 W
Redundant power supply (RPS) support
Y
Power supply
800 W
Redundant power supply (RPS) support
Y
PCI Express slots version
3.0
PCI Express slots version
3.0
Maximum graphics card memory
16 MB
Maximum graphic adapter memory
16 MB
On-board graphics card
Y
On-board graphics adapter
Y
Hard drive interface
Serial ATA
Number of hard drives supported
8
Maximum storage capacity
22 TB
Internal memory type
DDR4-SDRAM
Memory slots
24x DIMM
Maximum internal memory
1536 GB
ECC
Y
Internal memory type
DDR4-SDRAM
Memory slots
24x DIMM
Memory clock speed
2933 MHz
Maximum internal memory
1536 GB
ECC
Y
Memory layout (slots x size)
1 x 32 GB
Internal memory
32 GB
Memory clock speed
2933 MHz
Memory layout
1 x 32 GB
Internal memory
32 GB
Ethernet LAN
Y
Ethernet LAN connection
Y
Ethernet interface type
10 Gigabit Ethernet
Ethernet interface type
10 Gigabit Ethernet
Compatible operating systems
Windows Server 2019: Essentials, Standard, Datacenter Windows Server 2016: Essentials, Standard, Datacenter Windows Server 2012 R2: Essentials, Standard, Datacenter Microsoft Hyper-V Server: 2012 R2, 2016 & 2019 VMware vSphere: 6.0 U3, 6.5 U2 & 6.7 U1 ClearVM: 7.6 & 8.0 Red Hat Enterprise Linux (RHEL): 7.6 w/ Kbase SUSE Linux Enterprise Server (SLES): 12 SP4 & 15 SP1 (inc. Xen)
Operating system installed
N
Compatible operating systems
Windows Server 2019: Essentials, Standard, Datacenter Windows Server 2016: Essentials, Standard, Datacenter Windows Server 2012 R2: Essentials, Standard, Datacenter Microsoft Hyper-V Server: 2012 R2, 2016 & 2019 VMware vSphere: 6.0 U3, 6.5 U2 & 6.7 U1 ClearVM: 7.6 & 8.0 Red Hat Enterprise Linux (RHEL): 7.6 w/ Kbase SUSE Linux Enterprise Server (SLES): 12 SP4 & 15 SP1 (inc. Xen)
Operating system installed
N
Operating system provided
N
Optical drive type
N
Optical drive type
N
Compatible operating systems
Windows Server 2019: Essentials, Standard, Datacenter Windows Server 2016: Essentials, Standard, Datacenter Windows Server 2012 R2: Essentials, Standard, Datacenter Microsoft Hyper-V Server: 2012 R2, 2016 & 2019 VMware vSphere: 6.0 U3, 6.5 U2 & 6.7 U1 ClearVM: 7.6 & 8.0 Red Hat Enterprise Linux (RHEL): 7.6 w/ Kbase SUSE Linux Enterprise Server (SLES): 12 SP4 & 15 SP1 (inc. Xen)
Operating system installed
N
Ethernet LAN (RJ-45) ports
2
VGA (D-Sub) ports quantity
1
Ethernet LAN (RJ-45) ports quantity
2
VGA (D-Sub) ports quantity
1
Processor model
6248R
Motherboard chipset
Intel® C621
Number of processors installed
1
Processor manufacturer
Intel
Processor model
6248R
Processor lithography
14 nm
Maximum number of SMP processors
2
Processor family
Intel® Xeon® Gold
Motherboard chipset
Intel® C621
Processor socket
LGA 3647 (Socket P)
Number of processors installed
1
Supported instruction sets
SSE4.2,AVX,AVX 2.0,AVX-512
Processor manufacturer
Intel
Processor lithography
14 nm
Maximum number of SMP processors
2
Processor cores
24
Processor threads
48
Processor operating modes
64-bit
Processor boost frequency
4 GHz
Processor cache
35.75 MB
Execute Disable Bit
Y
Scalability
2S
Tcase
75 °C
Embedded options available
N
Processor family
Intel® Xeon® Gold
Processor frequency
3 GHz
Thermal Design Power (TDP)
205 W
Processor socket
LGA 3647 (Socket P)
Processor codename
Cascade Lake
Maximum number of PCI Express lanes
48
Maximum internal memory supported by processor
1024 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2933 MHz
Processor package size
76.0 x 56.5 mm
Supported instruction sets
SSE4.2,AVX,AVX 2.0,AVX-512
Processor generation
2nd Generation Intel® Xeon® Scalable
Processor number of cores
24
Processor threads
48
Processor operating modes
64-bit
Turbo frequency (max)
4 GHz
Processor cache
35.75 MB
Execute Disable Bit
Y
Scalability
2S
Tcase
75 °C
Embedded options available
N
Processor clock speed
3 GHz
Thermal Design Power (TDP)
205 W
Processor codename
Cascade Lake
Maximum number of PCI Express lanes
48
Maximum internal memory supported by processor
1024 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2933 MHz
Processor package size
76.0 x 56.5 mm
Processor generation
2nd Generation Intel® Xeon® Scalable
Intel® Hyper Threading Technology (Intel® HT Technology)
Y
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel 64
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
Processor ARK ID
199351
Intel Hyper-Threading Technology
Y
Intel Turbo Boost Technology
2.0
Intel AES New Instructions
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel 64
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
Processor ARK ID
199351
HDD interface
Serial ATA
Optical drive type
N
RAID levels
0,1,5,10
Hot-Plug support
Y
Number of HDDs supported
8
Hard drive interface
Serial ATA
Optical drive type
N
RAID levels
0,1,5,10
Maximum storage capacity
22 TB
Supported HDD sizes
2.5"
RAID support
Y
Hot-Plug support
Y
Number of hard drives supported
8
Maximum storage capacity
22 TB
Supported hard disk drive sizes
2.5"
RAID support
Y
RAID levels
0,1,5,10
RAID support
Y
Rack mounting
Y
Chassis type
Rack (1U)
Hot-Plug support
Y
Sustainability certificates
ENERGY STAR
Supported hard disk drive sizes
2.5"
Ethernet interface type
10 Gigabit Ethernet
Sustainability certificates
ENERGY STAR
Maximum graphic adapter memory
16 MB
Height
42.9 mm
Width
434.6 mm
Depth
707 mm
Height
42.9 mm
Width
434.6 mm
Depth
707 mm
