Fujitsu Network Adapters | FUJITSU 2x1Gbit Cu Intel I350-T2 | S26361-F4610-L502 | ServersPlus

Illustration purposes only

FUJITSU 2x1Gbit Cu Intel I350-T2

FUJITSU Logo here

Manufacturer Part Code: S26361-F4610-L502

Order Code: NPFUJ-S26361F461

Category: Fujitsu Network Adapters

Fujitsu PLAN CP 2 x 1Gbit Cu Intel I350-T2 PCIe x4 Card for PRIMERGY Servers

PLAN CP 2x1Gbit Cu Intel ® I350-T2

Trust the network communication of the new Ethernet LAN adapter. The new Intel® I350-T2 Ethernet LAN Adapter, based on the latest Intel® 1GbE chip technology, offers two Gigabit Ethernet ports for 10/100/1000BaseT.

Virtualization support and Wake-on-LAN with selectable port are just some of the features from which you will benefit. Optimal support for your virtualization is provided by the support for Virtual Machine Device Queues (VMDq), Single Root I/O virtualization and sharing specification (SR-IOV). SR-IOV requires corresponding support in the
system BIOS and in the operating system. PCI-SIG SR-IOV defines extensions of the PCI Express (PCIe) specification and enables PCI hardware resources to be shared with several system images or Virtual
Machines.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Data transfer rate (max)
1000 Mbit/s
Internal
Yes
Chipset
Intel® I350-AM2
Internal
Y
LED indicators
Yes
Chipset
Intel® I350-AM2
LED indicators
Y
Component for
Server
Recommended usage
Server
Component for
Server
Power consumption (typical)
4.4 W
Power consumption (typical)
4.4 W
LED indicators
Y
Harmonized System (HS) code
85176990
Supported network protocols
iSCSI
Cabling technology
10/100/1000BaseT(X)
Maximum data transfer rate
1000 Mbit/s
Ethernet LAN
Yes
Networking standards
IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Wake-on-LAN ready
Yes
Supported network protocols
iSCSI
Cabling technology
10/100/1000BaseT(X)
Chipset
Intel® I350-AM2
LAN controller
Intel® I350
Jumbo frames support
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Maximum data transfer rate
1000 Mbit/s
Ethernet LAN connection
Y
Networking standards
IEEE 802.1as,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3z
Wake-on-LAN ready
Y
Flow control support
Y
LAN controller
Intel® I350
Jumbo Frames support
Y
Ethernet LAN data transfer rates
10,100,1000 Mbit/s
Storage temperature (T-T)
-40 - 70 °C
Operating temperature (T-T)
0 - 55 °C
Storage temperature range (T-T)
-40 - 70 °C
Operating temperature range (T-T)
0 - 55 °C
Flow control support
Yes
Chipset
Intel® I350-AM2
Compatibility
Server
Flow control support
Y
Harmonized System (HS) code
85176990
Wake-on-LAN ready
Y
Interface
Ethernet
Interface
Ethernet
Internal
Y
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
2
Host interface
PCI Express
Connectivity technology
Wired
PCI version
2.1
Ethernet LAN (RJ-45) ports quantity
2
Host interface
PCI Express
PCI version
2.1
Supported network protocols
iSCSI
Compatibility
Server
Recommended usage
Server
Wake-on-LAN ready
Y
Ethernet LAN data transfer rates
10,100,1000 Mbit/s
