LENOVO ThinkSystem 10Gb Network adapter LOM x4

LENOVO Logo here

Manufacturer Part Code: 7ZT7A00549

Order Code: NPLEN-7ZT7A00549

Category: Lenovo Network Adapters

Lenovo ThinkSystem - Network adapter - LAN-on-motherboard (LOM) - 10Gb Ethernet x 4 - for ThinkAgile HX3321 Certified Node HX7520 Appliance ThinkAgile VX 1U Certified Node

The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.

ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.

The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Internal
Y
Certification
UL recognized to UL60950-1 2nd Edition FCC Rules, Part 15, Class A Australian EMC Framework (RCM) Japan VCCI, Class A Industry Canada, ICES-003, Class A EU (CE Mark) Korea KC-RRA, Class A
Chipset
Intel® C624
Product colour
Green
Compatible products
SR630 SR650 SR850 SR860 SR950
Harmonized System (HS) code
85176990
Security algorithms
SNMP
Cabling technology
10GBase-T
Maximum data transfer rate
10000 Mbit/s
Ethernet LAN
Y
Networking standards
IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
Quality of Service (QoS) support
Y
Jumbo frames support
Y
Ethernet LAN data rates
10,100,1000,10000 Mbit/s
VLAN tagging
Y
Jumbo frames
9728
Flow control support
Y
Number of VLANs
4096
PCI-SIG* SR-IOV Capable
Y
Receive Side Scaling (RSS)
Y
Harmonized System (HS) code
85176990
Interface
Ethernet
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
4
Host interface
PCI Express
Sustainability certificates
RoHS
Linux operating systems supported
Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2
Server operating systems supported
Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
Other operating systems supported
VMware vSphere ESXi
