Server Finder | LENOVO ThinkSystem SR650 Rack Server - 7X06A0PSEA | 7X06A0PSEA | ServersPlus
LENOVO 7X06A0PSEA | serversplus.com

Illustration purposes only

LENOVO ThinkSystem SR650 Rack Server - 7X06A0PSEA

LENOVO Logo here

Manufacturer Part Code: 7X06A0PSEA

Order Code: SVLEN-7X06A0PSEA

Category: Server Finder

Lenovo ThinkSystem SR650 7X06 - Server - rack-mountable - 2U - 2-way - 1 x Xeon Silver 4210R / 2.4 GHz - RAM 32 GB - SAS - hot-swap 2.5 bay(s) - no HDD - G200e - no OS - monitor: none

Future defined data center
Lenovo delivers cost-effective, reliable, and scalable solutions by combining industry-leading technology and the world's best software-defined offerings with Lenovo ThinkShield, XClarity, and TruScale Infrastructure Services to manage the life cycle of your data center needs. ThinkSystem SR650 provides support for data analytics, hybrid cloud, hyperconverged infrastructure, video surveillance, high performance computing and much more.

Workload-optimized support
Intel® Optane™ DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offer an unprecedented combination of high capacity, affordability, and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware.*
* Based on Intel internal testing, August 2018.

Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.

Empowering IT management
Lenovo XClarity Controller is the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks. Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95% versus manual operation. Running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Rack mounting
Y
Chassis type
Rack (2U)
Product colour
Black, Metallic
Redundant fans support
Y
Rack rails
Y
Power supply
750 W
Power supply input frequency
50 - 60 Hz
Redundant power supply (RPS) support
Y
Maximum graphics card memory
16 MB
On-board graphics card model
Matrox G200e
On-board graphics card
Y
Internal memory type
DDR4-SDRAM
Memory clock speed
2933 MHz
Memory layout (slots x size)
1 x 32 GB
Internal memory
32 GB
Cabling technology
10/100/1000Base-T(X)
Ethernet LAN
Y
Compatible operating systems
Microsoft Windows Server 2016 Microsoft Windows Server 2012 R2 Red Hat Enterprise Linux 7.4 Red Hat Enterprise Linux 7.3 Red Hat Enterprise Linux 6.9 Server x64 Edition SUSE Linux Enterprise Server 12 SP3 SUSE Linux Enterprise Server 12 SP2 SUSE Linux Enterprise Server 11 for AMD64/EM64TSP4 VMware vSphere 6.5 (ESXi) Update 1 VMware vSphere 6.5 (ESXi) VMware vSphere 6.0 (ESXi) Update 3
Operating altitude
0 - 3050 m
Operating relative humidity (H-H)
8 - 90%
Storage temperature (T-T)
-40 - 60 °C
Operating temperature (T-T)
5 - 45 °C
Storage relative humidity (H-H)
8 - 90%
Performance management
XClarity Enterprise
Trusted Platform Module (TPM)
Y
USB 2.0 ports quantity
1
VGA (D-Sub) ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
Processor model
4210R
Motherboard chipset
Intel® C624
Number of processors installed
1
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor boost frequency
3.2 GHz
Processor cache
13.75 MB
Execute Disable Bit
Y
Embedded options available
Y
Processor frequency
2.4 GHz
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel 64
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
Optical drive type
N
RAID levels
0, 1, 5, 6, 10, 50, 60
Internal drive bays
8
RAID support
Y
Supported RAID controllers
9350-8i
Height
87 mm
Width
445 mm
Depth
764 mm
