HPE ProLiant ML110 Gen10 Tower Server - P21449-421

HPE Logo here

Manufacturer Part Code: P21449-421

Order Code: SVHEW-P21449421

Category: HPE Tower Servers

Intel Xeon-S 4210R 10-Core (2.40GHz 13.75MB) 16GB (1 x 16GB) PC4-2933Y-R DDR4 RDIMM 8 x Hot Plug 2.5in Small Form Factor Smart Array P408i-p SR No Optical 800W 3yr Next Business Day Warranty

Are you searching for a tower server with enterprise-class reliability and performance at an exceptional value to meet your requirements? The HPE ProLiant ML110 Gen10 server is an enhanced single processor tower with performance, expansion, and security at an affordable price. It supports the Intel® Xeon® Scalable processor, HPE DDR4 SmartMemory with a maximum capacity of 192 GB, five PCIe slots, eight large form factor (LFF) or 16 small form factor (SFF) disk drives. It can easily be converted to a rack using 4.5U of rack space. The HPE ProLiant ML110 Gen10 server also offers optional redundant fan and redundant power supply to satisfy automatic fail-over needs, making this the ideal server for small- to mid-sized businesses, and remote and branch offices.

Features

Right-sized, With the Balance of Performance To Meet Growing SMB Requirements
- The HPE ProLiant ML110 Gen10 Server is compact with less than a 19-inch depth, quiet, and affordable that can deliver the performance needed for the compute demands of a growing office small- to mid-sized business.
- Supports industry standard technology leveraging the Intel Xeon Scalable Processors operating with speeds of up to 3.6 GHz and up to 14 cores offering improved performance.
- Supports up to two optional graphic processing units (GPUs) allowing one double wide and one single wide card to boost performance in graphic and Virtual Desktop Infrastructure (VDI) applications such as financial services, education, scientific research and medical imaging.
- The embedded HPE Dynamic Smart Array S100i Controller for SATA disk drives supports boot, data and media needs. These enhanced HPE Smart Array Controllers provide the flexibility to choose the optimal 12 Gbps controller most suited to your environment, as well as operate in both SAS and HBA modes.
- Build a fully functional server with ClearOS Software from Hewlett Packard Enterprise that is just right for you at no upfront cost.

Expandability To Fit the Needs of Growing, Budget-conscious Businesses
- The HPE ProLiant ML110 Gen10 Server offers up to six DIMM slots with support for up to 192 GB of HPE DDR4 SmartMemory, helping to prevent data loss and downtime with enhanced error handling while improving workload performance and power efficiency.
- Support optional redundant fan and redundant power supplies reducing data loss and downtime, making your server more reliable. Flexible expansion capacity with five PCIe expansion slots, eight USB ports and one optional serial port.
- HPE SmartDrives delivers enhanced performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics. Support up to eight large form factor (LFF) disk drives or 16 small form factor (SFF) disk drive options.

Security Innovations
- The HPE ProLiant ML110 Gen10 Server is part of the Hewlett Packard Enterprise offering of industry-standard servers with major firmware anchored directly into the silicon. With security protection built-in across the server lifecycle starting with Silicon Root of Trust.
- Secure Recovery allows server firmware to roll back to the last known reliable state or factory settings after detection of compromised code.
- Millions of lines of firmware code run before server operating system boots and with Run-time Firmware Validation, enabled by HPE iLO Advanced Premium Security Edition, the server firmware is checked every 24 hours verifying validity and credibility of essential system firmware.

Industry-Leading Services and Ease of Deployment
- The HPE ProLiant ML110 Gen10 Server comes with a complete set of services from HPE Pointnext, delivering confidence, reducing risk, and helping you realize agility and stability.
- HPE Pointnext Services simplifies all stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an enchanced solution. Professional Services enables rapid deployment of solutions and Operational Services provides ongoing support.
- Services provided under Operational Services include: HPE Flexible Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services and multi-vendor coverage.
- HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.
Need this delivered pre-built? We have configuration and installation options available!

Essential Extras and Accessories

£29.68 ex. VAT
£22.14 ex. VAT
£99.50 ex. VAT
£146.54 ex. VAT
£213.08 ex. VAT
£69.62 ex. VAT
£210.79 ex. VAT
£277.25 ex. VAT
£229.51 ex. VAT

Technical Information

Energy Star certified
Y
Chassis type
Tower (4.5U)
Product colour
Black
Chassis type
Tower (4.5U)
Optical drive type
N
Colour of product
Black
Power supply
800 W
Redundant power supply (RPS) support
Y
Power supply
800 W
Redundant power supply (RPS) support
Y
PCI Express slots version
3.0
PCI Express slots version
3.0
Maximum graphics card memory
16 MB
Maximum graphic adapter memory
16 MB
On-board graphics card model
Not available
On-board graphics card
Y
On-board graphics adapter model
Not available
On-board graphics adapter
Y
Hard drive interface
Serial ATA, Serial Attached SCSI (SAS)
Number of hard drives supported
8
Maximum storage capacity
38.4 TB
Harmonized System (HS) code
84714100
Remote administration
iLO 5 ASIC
Internal memory type
DDR4-SDRAM
Memory slots
6x DIMM
Maximum internal memory
192 GB
Internal memory type
DDR4-SDRAM
Memory slots
6x DIMM
Memory clock speed
2933 MHz
Maximum internal memory
192 GB
Memory layout (slots x size)
1 x 16 GB
Internal memory
16 GB
Memory clock speed
2933 MHz
Memory layout
1 x 16 GB
Internal memory
16 GB
Ethernet LAN
Y
LAN controller
HP 332i
Ethernet LAN connection
Y
Ethernet interface type
Gigabit Ethernet
LAN controller
HP 332i
Ethernet interface type
Gigabit Ethernet
Compatible operating systems
Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware ClearOS
Operating system installed
N
Compatible operating systems
Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware ClearOS
Operating system installed
N
Operating system provided
N
Optical drive type
N
Optical drive type
N
Remote administration
iLO 5 ASIC
Remote administration
iLO 5 ASIC
Trusted Platform Module (TPM)
N
Trusted Platform Module (TPM) version
2.0
Compatible operating systems
Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware ClearOS
Harmonized System (HS) code
84714100
Operating system installed
N
Trusted Platform Module (TPM)
Y
Trusted Platform Module (TPM) version
2.0
USB 2.0 ports quantity
3
Ethernet LAN (RJ-45) ports
2
VGA (D-Sub) ports quantity
1
USB 2.0 ports quantity
3
Ethernet LAN (RJ-45) ports quantity
2
VGA (D-Sub) ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
Processor model
4210R
Motherboard chipset
Intel® C621
Number of processors installed
1
Processor manufacturer
Intel
Processor model
4210R
Processor lithography
14 nm
Processor family
Intel Xeon Silver
Motherboard chipset
Intel® C621
Processor socket
LGA 3647 (Socket P)
Number of processors installed
1
Supported instruction sets
SSE4.2, AVX, AVX 2.0, AVX-512
Processor manufacturer
Intel
Processor lithography
14 nm
Processor cores
10
Processor threads
20
Processor operating modes
64-bit
Processor boost frequency
3.2 GHz
Processor cache
13.75 MB
Execute Disable Bit
Y
Scalability
2S
Tcase
84 °C
Embedded options available
Y
Processor family
Intel Xeon Silver
Processor frequency
2.4 GHz
Thermal Design Power (TDP)
100 W
Processor socket
LGA 3647 (Socket P)
Processor codename
Cascade Lake
Maximum number of PCI Express lanes
48
Maximum internal memory supported by processor
1024 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2400 MHz
Processor package size
76.0 x 56.5 mm
Supported instruction sets
SSE4.2,AVX,AVX 2.0,AVX-512
Processor generation
2nd Generation Intel® Xeon® Scalable
Processor number of cores
10
Processor threads
20
Processor operating modes
64-bit
Turbo frequency (max)
3.2 GHz
Processor cache
13.75 MB
Execute Disable Bit
Y
Scalability
2S
Tcase
84 °C
Embedded options available
Y
Processor clock speed
2.4 GHz
Thermal Design Power (TDP)
100 W
Processor codename
Cascade Lake
Maximum number of PCI Express lanes
48
Maximum internal memory supported by processor
1024 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2400 MHz
Processor package size
76.0 x 56.5 mm
Processor generation
2nd Generation Intel® Xeon® Scalable
Intel® Hyper Threading Technology (Intel® HT Technology)
Y
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel 64
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
Processor ARK ID
197098
Intel Hyper-Threading Technology
Y
Intel Turbo Boost Technology
2.0
Intel AES New Instructions
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel 64
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
Processor ARK ID
197098
HDD interface
Serial ATA, Serial Attached SCSI (SAS)
Optical drive type
N
RAID levels
0, 1, 1 ADM, 5, 6, 10 ADM, 10, 50, 60
Hot-Plug support
Y
Number of HDDs supported
8
Hard drive interface
Serial ATA, Serial Attached SCSI (SAS)
Optical drive type
N
RAID levels
0,1,1 ADM,5,6,10 ADM,10,50,60
Maximum storage capacity
38.4 TB
Supported HDD sizes
2.5"
RAID support
Y
Hot-Plug support
Y
Number of hard drives supported
8
Maximum storage capacity
38.4 TB
Supported hard disk drive sizes
2.5"
RAID support
Y
RAID levels
0,1,1 ADM,5,6,10 ADM,10,50,60
RAID support
Y
Chassis type
Tower (4.5U)
Hot-Plug support
Y
Trusted Platform Module (TPM)
Y
Sustainability certificates
ENERGY STAR
Supported hard disk drive sizes
2.5"
Ethernet interface type
Gigabit Ethernet
Trusted Platform Module (TPM) version
2.0
Sustainability certificates
ENERGY STAR
Maximum graphic adapter memory
16 MB
Height
440 mm
Width
195 mm
Depth
480.5 mm
Height
440 mm
Width
195 mm
Depth
480.5 mm
