Vertiv GXT51000VA

Vertiv Logo here

Manufacturer Part Code: GXT5-1000IRT2UXLE

Order Code: PSEME-GXT51000IR

Category: Vertiv Rack UPS

GXT5 1000VA 230V UPS EU

The Vertiv Liebert GXT5 UPS 1000VA/1000W, is a 2U UPS solution for ensuring the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance without drawing on battery power, extending battery life and minimizing replacements. This can support a wide range of power environment including 200/208/220/230/240V user configurable AC power and has scalable runtime options with matching external battery cabinets to offer extra time during an outage to support critical equipment and activity. It includes hot-swappable batteries and all hardware for installing it as a tower or in an equipment rack. This single-phase UPS is ENERGY STAR 2.0 certified and offers leading normal mode power efficiency and Eco-mode for ultimate efficiency levels. It has a two-year factory warranty. It offers premium power protection for critical infrastructure in centralized and edge applications.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Battery technology
Sealed Lead Acid (VRLA)
Battery recharge time
3 h
Typical backup time at half load
15 min
Typical backup time at full load
6 min
Hot-swap battery
Yes
Battery voltage
12 V
Battery capacity
9 VAh
Display
LCD
Certification
IEC/EN/AS 62040-2 2nd Ed (Cat 2 – 6); FCC 15 A CISPR22 A(RFI)
Safety
IEC62040-1:2008, GS; UL1778, c-UL
Form factor
Rackmount/Tower
Product colour
Black
International Protection (IP) code
IP20
Display type
LCD
Audible alarm(s)
Yes
Emergency Power Off (EPO)
Yes
Output power capacity
1 kVA
Noise level
58 dB
Input frequency
40 - 70 Hz
Efficiency
95%
Output power
1000 W
Power protection features
Overload
Input operation voltage (max)
288 V
Input operation voltage (min)
115 V
Output operation voltage (max)
240 V
Output frequency
50/60 Hz
Number of input phases
1
Number of output phases
1
Input power factor
0.99
Waveform
Pure sine
Output voltage regulation
3%
UPS topology
Double-conversion (Online)
Efficiency (On-line mode)
95%
Efficiency (ECO mode)
98%
Harmonized System (HS) code
85078000
Operating altitude
0 - 3000 m
Operating relative humidity (H-H)
0 - 95%
Storage temperature (T-T)
-15 - 40 °C
Operating temperature (T-T)
0 - 40 °C
Storage relative humidity (H-H)
0 - 95%
Non-operating relative humidity (non-condensing)
0 - 95%
Battery type
VRLA
Nominal output voltage
230 V
Output connections
IEC320 C13
Input connection type
C14
Nominal input voltage
230 V
Overload protection
Yes
Bypass
Yes
Package weight
21.4 kg
Package depth
262 mm
Package height
617 mm
Package width
517 mm
Serial interface type
RS-232, RS-485
Serial ports quantity
1
AC outlets quantity
8 AC outlet(s)
AC outlet types
C13 coupler, C19 coupler
Emergency Power Off (EPO) connector
Yes
USB port
Yes
Harmonized System (HS) code
85078000
Sustainability certificates
RoHS, ENERGY STAR
Weight
21 kg
Package weight
21.4 kg
Height
217 mm
Width
430 mm
Depth
630 mm
Package depth
262 mm
Package height
617 mm
Package width
517 mm
