QNAP TS-h1090FU

TS-h1090FU
ZFS-based, 1U high-density U.2 NVMe PCIe Gen 4 / SATA 6Gbps SSD all-flash storage built for low-latency file servers, virtualized workloads, data centers, and 4K/8K streams

The TS-h1090FU high-density NVMe all-flash storage is designed for providing extreme performance with high cost-efficiency. Featuring ten U.2 NVMe Gen 4 x4 SSD bays, the TS-h1090FU delivers remarkable random read/write IOPS with ultra-low latency. The ZFS-based QuTS hero operating system supports inline data deduplication and compression for reducing I/O and SSD storage consumption, which significantly extends SSD lifespan with a higher price-performance ratio for all-flash storage arrays. Ideal for I/O-intensive and latency-sensitive applications, the TS-h1090FU eliminates productivity bottlenecks in virtualization, modern data centers, multimedia storage, and mission-critical backup/restore tasks-suitable for Tier 2 storage workloads with an ideal low cost-per-GB.

Build high-performance storage infrastructure for IOPS-demanding applications

Virtualization
Eliminates storage bottlenecks for unstructured data and I/O intensive workloads; ideal for server virtualization and virtual desktop infrastructure (VDI).

Data Centers
Delivers ultra-low latency and high IOPS performance, providing response times within microseconds for data centers that host significant business-critical systems and data.

Media and Entertainment (M&E) production
Satisfies smooth 4K/8K media streaming and post-production, empowering multimedia workflows with faster data transfer, access, and backup for boosted efficiency.

Powerful, reliable, and multitasking with up to 1 TB DDR4 ECC memory
The TS-h1090FU is armed with 2nd Gen AMD EPYC™ 7002 series processors (Rome), based on the ?Zen 2? architecture with cutting-edge 7nm process technology. With DDR4 ECC memory that detects and corrects single-bit memory errors for higher reliability, the TS-h1090FU provides 12 Long-DIMM slots for up to 1 TB memory to fulfill memory-intensive workloads. Demonstrating immense computing power and multi-tasking capabilities, the TS-h1090FU is the ideal choice for uncompromising performance demands in HPC, virtualization, and 4K/8K multimedia applications.

U.2 NVMe PCIe Gen 4 x4 – faster speed, optimal I/O, and lower latency
The 1U rackmount TS-h1090FU has 10 drive bays that support high-performance U.2 NVMe PCIe Gen 4 x4 SSDs or economical SATA 6Gb/s SSDs. Latency-sensitive applications can be bolstered with U.2 NVMe PCIe SSDs to attain optimized performance and utmost application response times. Coupled with powerful ZFS data deduplication and SSD optimization technologies, the TS-h1090FU provides solid foundations for overcoming performance demands while also maximizing your SSD investments!

Leverage the M.2 PCIe NVMe SSD to U.2 Adapter
Install one or more QDA adapters in the TS-h1090FU to maximize PCIe bandwidth utilization in a cost-effective way by using M.2 PCIe NVMe SSD instead of the U.2 SSD for optimizing data-intensive applications. It can also boost IOPS performance when configuring SSD caching. Users can monitor drive health and manage SSD usage from the QTS Storage & Snapshots Manager. The M.2 SSD installed in the QDA adapter is hot swappable.

Dual 25GbE connectivity multiplies all-flash superior performance
The NVMe-ready TS-h1090FU provides breakthrough network connectivity with two 25GbE SFP28 SmartNIC ports (compatible with 10GbE SFP+ / 1GbE SFP) that also support iSCSI Extensions for RDMA (iSER) to increase performance of data transfer between NAS and VMware® ESXi server and offload CPU workloads. With Port Trunking and Auto-Negotiation, the TS-h1090FU empowers your organization with the bandwidth and reliability to allow thousands of endpoint users to smoothly access data stored on the NAS while satisfying the most performance-demanding applications. The TS-h1090FU is also ideally matched with QNAP's managed and unmanaged 2.5GbE/10GbE/25GbE switches to form high-speed, secure, and scalable network environments without going over budget.

Multiple PCIe Gen 4 slots for flexible expansion
The TS-h1090FU is equipped with two PCIe Gen 4 slots. With twice the I/O performance of PCIe Gen 3, the TS-h1090FU can take advantage of PCIe cards to expand application potential.

Robust hardware paralleled to boost all-flash NVMe performance
TS-h1090FU features high-level hardware with an expandable architecture to provide businesses with high performance and low latency access.

ZFS-based QuTS hero operating system enhances NAS performance and data integrity
QuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.

Data integrity is key
QuTS hero's self-healing ensures data integrity and reliability. Write Once, Read Many (WORM) is also supported.

Data reduction improves storage efficiency and performance
Inline data deduplication, compression, and compaction reduce file sizes to conserve storage capacity and optimize performance.

Multi-level cache technology
Main memory read cache (L1 ARC), SSD second-level read cache (L2 ARC), and ZFS Intent Log (ZIL) for synchronous transactions with power failure protection are supported to boost performance and security.

RAID Z enables robust data protection
Multiple RAID levels allow flexible capacity utilization. RAID Triple Parity and Triple Mirror deliver higher levels of data protection.

QSAL (QNAP SSD Antiwear Leveling) enhances data protection
RAID-level SSD lifespan is automatically and reg
