Synology NAS Storage | SYNOLOGY SA3400 12 Bay NAS Server | SA3400 | ServersPlus
L R
SYNOLOGY SA3400 | serversplus.comSYNOLOGY SA3400 | serversplus.comSYNOLOGY SA3400 | serversplus.comSYNOLOGY SA3400 | serversplus.comSYNOLOGY SA3400 | serversplus.comSYNOLOGY SA3400 | serversplus.com

Illustration purposes only

SYNOLOGY SA3400 12 Bay NAS Server

SYNOLOGY Logo here

Manufacturer Part Code: SA3400

Order Code: NSSYN-SA3400

Category: Synology NAS Storage

Synology SA3400 - NAS server - 12 bays - rack-mountable - RAID 0 1 5 6 10 JBOD RAID F1 - RAM 16 GB - Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 2U

Highly scalable storage with uncompromising performance
Equipped with an 8-core CPU and 16GB ECC RDIMM memory, SA3400 delivers sequential throughput at over 5,520 MB/s and 304,277 random IOPS. Built-in 10GbE Ethernet, PCIe expansions, and the support for both SAS and SATA drives provide resilient configurability with fast data transmission, fulfilling modern enterprises' needs for excellent performance and massive storage scalability simultaneously.

Small-to-hyperscale flexibility
Scalable up to 180/96 drives delivering more than 1.5 petabytes raw capacity, SA3400 can easily fulfill extensive storage needs, including video post-production and massive surveillance deployment.

Supercharge network performance effortlessly
Built-in dual 10GbE Ethernet ports and dual PCIe 3.0 slots provide high-speed network transmission with additional network interface cards' expansion.

Btrfs: Next generation storage efficiency
Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:

- Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
- Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
- File or folder level data restoration makes data recovery fast and flexible
- Automatic file self-healing detects and recovers corrupted files without user intervention

Ultimate Backup Solution
SA3400 integrates various backup applications to safeguard your important data on any device with an intuitive user interface and durable storage technologies.

Fully certified storage virtualization solutions
Synology iSCSI storage fully supports most virtualization solutions to enhance work efficiency with easy management interface. VMware vSphere 6 and VAAI integration helps offload storage operations and optimizes computation efficiency. Windows Offloaded Data Transfer (ODX) speeds up data transfer and migration rate. OpenStack Cinder support turns your Synology NAS into a block-based storage component.


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Certification
EAC VCCI CCC RCM KC FCC CE BSMI
Chassis type
Rack (2U)
LED indicators
HDD, Power
Product colour
Black
Chassis type
BTRFS, Fat, HFS+, NTFS, ext3, ext4
Number of fans
4 fan(s)
Cooling type
Active
Fan diameter
8 cm
Power consumption (typical)
137.17 W
Redundant power supply (RPS) support
Yes
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Power supply location
Built-in
Power supply unit (PSU) capacity
500 W
Power consumption (HDD standby)
70.95 W
Harmonized System (HS) code
84714100
Internal memory type
DDR4
Memory slots
4
Maximum RAM supported
128 GB
Internal memory
16 GB
Supported network protocols
CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
Ethernet LAN
Yes
Wake-on-LAN ready
Yes
Wi-Fi
No
Link aggregation
Yes
Ethernet LAN data rates
10,100,1000,10000 Mbit/s
iSCSI support
Yes
Ethernet LAN data rate supported (max)
10000 Mbit/s
Operating relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-20 - 60 °C
Operating temperature (T-T)
0 - 35 °C
Certification
EAC VCCI CCC RCM KC FCC CE BSMI
Processor ARK ID
91199
Digital Living Network Alliance (DLNA) certified
Yes
Compliance certificates
RoHS
Cables included
AC
Quick installation guide
Yes
Type
NAS
Security algorithms
HTTPS, SSH, SSL/TLS
Browser supported
Chrome, Firefox, Edge, Internet Explorer 10+, Safari 10+
Noise level
49.8 dB
Snapshot
Yes
Web-based management
Yes
Access Control List (ACL)
Yes
Reset button
Yes
Multilingual support
Yes
On/off switch
Yes
Device class
Large Enterprise Business
Backup function
Yes
Backup features
Cloud, iSCSI LUN
System log
Yes
Ethernet LAN (RJ-45) ports
6
PCI Express x8 (Gen 3.x) slots
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB port
Yes
Expansion ports quantity
1
Processor model
D-1541
Processor manufacturer
Intel
Processor lithography
14 nm
Processor family
Intel® Xeon® D
Processor socket
BGA 1667
Stepping
V2
Processor cores
8
Processor code
SR2DE
Processor threads
16
PCI Express slots version
2.0, 3.0
Processor operating modes
64-bit
Processor boost frequency
2.7 GHz
On-board graphics card model
Not available
Processor cache
12 MB
Scalability
1S
CPU configuration (max)
1
PCI Express configurations
1x16, 1x4, 1x8
Processor frequency
2.1 GHz
Thermal Design Power (TDP)
45 W
Processor codename
Broadwell
Processor series
Intel Xeon D-1500
Maximum internal memory supported by processor
128 GB
Processor package size
37.5 x 37.5 mm
Conflict-Free processor
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Execute Disable Bit
Yes
Idle States
Yes
Thermal Monitoring Technologies
Yes
Intel Trusted Execution Technology
Yes
Intel Enhanced Halt State
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Embedded options available
No
Intel TSX-NI
Yes
Intel® Secure Key
Yes
Intel 64
Yes
Intel® OS Guard
Yes
UART
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Maximum number of PCI Express lanes
32
Intel Secure Key Technology version
1.00
Intel Virtualization Technology (VT-x)
Yes
Intel TSX-NI version
1.00
Memory types supported by processor
DDR3-SDRAM, DDR4-SDRAM
Operating system installed
DiskStation Manager
Windows operating systems supported
Windows 10, Windows 7
Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Server operating systems supported
Windows Server 2016
RAID levels
0, 1, 5, 6, 10, F1, JBOD
Supported file systems
BTRFS, Fat, HFS+, NTFS, ext3, ext4
RAID support
Yes
Storage drive interface
Serial ATA, Serial Attached SCSI (SAS)
Number of storage drives supported
12
Storage drive sizes supported
2.5,3.5"
Storage drives installed
No
Maximum supported storage capacity
192 TB
Installed storage drive type
No
Supported storage drive types
HDD & SSD
Hot-swap drive bays
Yes
Sustainability certificates
RoHS
Chassis type
BTRFS, Fat, HFS+, NTFS, ext3, ext4
Harmonized System (HS) code
84714100
Sustainability certificates
RoHS
Compliance certificates
RoHS
Weight
14.5 kg
Height
88 mm
Width
482 mm
Depth
724 mm
