Ubiquiti NS-5AC NanoStation AC 5GHz 16dBi airMAX Outdoor Wireless AC CPE Bridge

Ubiquiti Logo here

Manufacturer Part Code: NS-5AC

Order Code: NPUBI-NS5AC

Category: Ubiquiti AirMax

Ubiquiti NS-5AC NanoStation AC 5GHz 16dBi airMAX Outdoor Wireless AC CPE Bridge

5 GHz airMAX® ac CPE

The indoor/outdoor NanoStation® AC is a compact, high-performance CPE featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.

Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.

Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.

Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.

Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.

Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

Specifications

Model: NS-5AC
Frequency: 5 GHz
Throughput: 450+ Mbps
Range: 15+ KM
Management Radio: Yes
PoE PSU Included: Yes
802.3af Support: Yes
Secondary Ethernet Port with PoE Out: Yes


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Antenna gain level (max)
16 dBi
Internal
N
Certification
CE, FCC, IC
LED indicators
Network, Power, Signal strength
Product colour
White
Placement
Ceiling
Power over Ethernet (PoE)
Y
Input current
0.5 A
AC input voltage
24 V
Maximum data transfer rate
1000 Mbit/s
Channel bandwidth
80 MHz
Modulation
16-QAM,64-QAM,256-QAM,BPSK,QPSK
Ethernet LAN data rates
10,100,1000 Mbit/s
Maximum outdoor range
15000 m
5 GHz
Y
Throughput data rate
450 Mbit/s
Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-40 - 70 °C
PoE adapter included
Y
Internal memory
64 MB
Operating system installed
AirOS
Built-in processor
Y
Ethernet LAN (RJ-45) ports
2
Weight
233 g
Height
41 mm
Width
257 mm
Depth
84 mm
