APC Smart UPS On Line

APC Logo here

Manufacturer Part Code: SRT8KXLI

Order Code: PSAPC-SRT8KXLI

Category: APC Tower UPS

Smart-UPS On-Line

APC Smart-UPS On-Line,8000 Watts /8000 VA,Input 230V /Output 230V, Interface Port Contact Closure, RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB, Extended runtime model

Includes: CD with software, Documentation CD, Installation guide, Temperature Probe, USB cable, Warranty card


Business IT purchase over £1000? Spread the cost on a monthly basis with our flexible leasing options.

Technical Information

Battery technology
Sealed Lead Acid (VRLA)
Battery recharge time
1.5 h
Replacement battery cartridge
APCRBC140
Hot-swap battery
Y
Cold start
Y
Automatic battery test
Y
Battery capacity
1728 VAh
Battery life (max)
5 year(s)
Certification
REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Energy Star certified
Y
RoHS compliance
Y
Colour of product
Black
Display
LCD
Form factor
Rackmount/Tower
Colour of product
Black
International Protection (IP) code
IP20
Display
LCD
Power supply input frequency
40 - 70 Hz
Emergency Power Off (EPO)
Y
Output power capacity (VA)
8000 VA
Surge energy rating
480 J
Output power
8000 W
Output voltage THD
3%
Crest factor
3:1
Input operation voltage (max)
476 V
Input operation voltage (min)
100 V
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Output frequency regulation
50/60 Hz
LED indicators
status
Audible alarms
Y
Quantity per pallet
1 pc(s)
Operating altitude
0 - 3000 m
Operating relative humidity range
0 - 95%
Storage temperature range (T-T)
-15 - 45 °C
Operating temperature range (T-T)
0 - 40 °C
Storage relative humidity range
0 - 95%
Non-operating altitude
0 - 15000 m
Quantity per pallet
1 pc(s)
Cables included
USB cable
Warranty card
Y
Quick installation guide
Y
Packaging content
Web/SNMP Management Card
Software CD
Y
Temperature sensor
Y
Quantity per pallet
1 pc(s)
Package weight
126.8 kg
LED indicators
status
Audible alarms
Y
Noise level
55 dB
Surge protection
Y
Number of output phases
1
Waveform
Sine
Auto-restart
Y
UPS topology
Double-conversion (Online)
Serial interface type
RJ-45
AC outlets quantity
10 AC outlet(s)
Number of output IEC jumpers
3
AC outlet types
C13 coupler, C19 coupler
Serial interface
Y
USB port
Y
SmartSlot
Y
Noise level
55 dB
Form factor
Rackmount/Tower
Energy Star certified
Y
Input connections
Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G)
Surge protection
Y
Weight
111.8 kg
Package weight
126.8 kg
Height
432 mm
Width
263 mm
Depth
715 mm
Packaging depth
1000 mm
Packaging height
461 mm
Packaging width
600 mm
